Description

This Standard covers knurling tools with diametral pitches. Dim relations of straight, diag, & diamond knurl on cylindrical surfaces with uniform pitch teeth parallel to or at helix angle below 45deg.
Standard maintained stabilized maintenance. maintenance option requires status review every 10 years rather revision reaffirmation 5 years. standards committee shall consider requests recommendations change materially affected interested party. request made writing include rationale particular order facilitate committee. covers knurling tools standardized diametral pitches includes dimensional relations stock production straight, diagonal, diamond cylindrical surfaces teeth uniform pitch parallel axis cylinder helix angle not exceeding 45 deg. work. displacement material surface rotated pressure tool. equally applicable general purpose precision knurling. brief, advantage method provision good tracking (the ability mesh tool penetrates work blank successive revolutions) obtained designed basis instead tpi (teeth per inch) used recommended diameters multiples 1/64 1/32in.
