ASME B5.50 PDF
Original price was: $38.00.$25.84Current price is: $25.84.
7/24 Taper Tool to Spindle Connection for Automatic Tool Change
Description
This Standard provides for tool holder shank and retention knob assemblies the inch solution to tool holder interchangeability between various machining centers and automatic tool changers.
Standard pertains standardization basic tool holder shank retention knob numerically-controlled machining centers automatic changers. requirements contained herein intended provide interchangeability changers various types. dimensions cone-angle control accordance international iso-1947. will improve understanding “cat” toolholder, associated components, nominal operational values. unifies principle components machine interface—toolholder spindle receiver geometry, pull stud, conical taper information—into single-source reference, providing instant access information. new information also eliminates ambiguities establishes absolutes aspects toolholder/spindle interface. for: involved design, manufacture, use, maintenance steep-taper (7:24) toolholders ancillary components.
