Description

This Standard provides configurations, tolerances, dimensions, numbering systems and measuring loads for silent chains; also dimensions and tolerances for sprockets.
Standard includes following information inverted tooth (silent) chains: (a) nomenclature; (b) general configuration; (c) numbering system; (d) tolerance chain length; (e) measuring loads; (f) dimensions 3/8 in. pitch larger; (g) widths sprocket-face profiles larger 3/16 chain. also sprockets: form chain; diameters tolerances diameters, pin eccentricity hub tabulation diameter, outside guide groove diameter chain.  included "supplementary information" contains suggestions relative application use chains covered standard. sprockets provides configurations, tolerances, dimensions, systems loads silent chains; sprockets.
