ASME B18.29.2M PDF

Description

This Standard delineates the dimensional, mechanical, and performance data for the metric series helical coil screw thread insert and threaded hole into which it is installed.
Standard maintained stabilized maintenance. maintenance option requires status review every 10 years rather revision reaffirmation 5 years. standards committee shall consider requests recommendations change materially affected interested party. request made writing include rationale particular order facilitate committee. delineates dimensional, mechanical, performance data metric series helical coil screw thread insert threaded hole installed. appendices describe selection, sti (screw insert) taps, installation, removal tooling also included. inclusion dimensional not intended imply products described stock sizes.
