ASME B18.29.1 PDF

Description

This Standard is intended to delineate the dimensional data for the inch series helical coil screw thread insert and the threaded hole into which it is installed.
Standard maintained stabilized maintenance. maintenance option requires status review every 10 years rather revision reaffirmation 5 years. standards committee shall consider requests recommendations change materially affected interested party. request made writing include rationale particular order facilitate committee. intended delineate dimensional data inch series helical coil screw thread insert threaded hole installed. appendices describe selection, sti (screw insert) taps, gages gaging, installation, removal tooling also included.  inclusion not imply products described stock sizes. consumers consult manufacturers concerning availability.
